CP-L80
– 🔄 **360° x 270° Scanning** – Captures full spatial point cloud
– 🎯 **Up to 80m Range** – Measures large stockpiles and vehicle loads with ±20mm accuracy
– ❄️ **Anti-Fog, Self-Heating Design** – Operates reliably in cold, dusty, and foggy environments
– 🛡️ **IP65 Industrial Protection** – Dust-proof, waterproof, and built for tough outdoor conditions
– ⚡ **High-Frequency Scanning (100Hz)** – Suitable for fast-moving objects and dynamic scenes
Design
Engineered for Accuracy. Built for Industry.
Parameter
CP-L 80
Scanning Angle
270°*360°
Detection Range
30m@10%; 80m@90%
Scan Rate
25/50Hz
Angular Resolution
0.25/0.5°
Laser divergence angle
6±1mrad
Accuracy
±30mm; ±20mm(Repeat)
Operating Temp
Wide-temperature version: -55°C to +80°C;
Standard version: -20°C to +55°C
Response Time
90±20ms
Laer Rate
36k
Humidity Tolerance
0%～95%
Power consumption
Typical ≤18W, heating ≤58W
Operating voltage
24V DC
Light Resistance
80000lx
Impact resistance
IEC 60068-2-27
Electromagnetic compatibility
IEC 61000-6-4/IEC 61000-6-2
Protection Rating
IP65
Application
Smart Applications
Talk to Our Experts Today
Need a custom LiDAR solution? Our engineers are here to support your industrial project.
